綜合送料縫紉機 >GA441S型筒式綜合送料極厚料平縫機



性能優點:采用綜合送料方式和圓筒形縫合。送量力穩定，能輕易車縫多層厚重物料，線跡精準美觀。采用進口大型特種擺梭，梭芯線量大，縫制效率高。梭芯繞線裝置位于機頭 上部，壓腳提升量可達23毫米，可適用于縫制手提袋的手把、棒球手套、運動器材、安全貸、帳篷、坐墊、箱包等厚料和極厚料物品。位于機頭頂部的硅油盒，用來潤滑縫絲和冷卻機針，使用非常方便，縫制品的線跡更美觀、挺括。
Advantages：The feeding power is stable and strong so that it is able to sew multiplayer extra-thick material easily with nice and accurate stiches.It also adopts imported large-scale special type shuttle hook that has a large amount of bobbin thread with high sewing efficiency.Bobbin winding device is located at the top of machine head and presser's lifting capacity can be 20mm.This type of sewing machine is applicable for thick and extreme-thick material such as handlebar of handbag,baseball gloves,sports appatently,safety belt,tent,seat cushion and luggages,Silicone oil bos,located at the of machine head,is used to lubricate seams and cool needle that is very convenient and the stitch is much more beautiful,stiffer and smoother.
主要技術規格Main Parameters:
??? 型號 Mode
GA441S

?   縫速 Max.Sewing speed

800 r.p.m
??? 線跡長度 Stitch length
0-11mm
    挑線桿行程  Thread take-up lever stroke
96mm
??? 針桿行程 Needie bar stroke
56mm
    壓腳提升 Presser foot lift
手動By hand
13mm
膝控By knee
23mm
??? 擺梭 Shuttle hook
KSP-204N
??? 機針  Needle size
DYx3 27#
    潤滑方式 Lubrication mode
手工潤滑 Manual
    電動機 Motor
550w 4p

??? 縫臺筒徑  Bed Size in dia

81mm
